This cable lubricant incorporates new lubricant technology to create a high-performance, water-based pourable lubricant formulated for many applications, such as fiber optic, coaxial, 600 V and higher voltage-rated cables. It is designed to meet or exceed all cable pulling requirements with respect to viscosity, cling, drag, wetting, operational temperature range and reduction of pulling tension.
Features
- New technology for increased friction reduction; Will not be displaced by cables
- Very effective for placement of fiber optic, coaxial and other communications cables
- Effective for placing larger cables in short runs
- Can be poured or pumped
- Compatible with all types of cable jackets
- Slow drying, leaves a lubricating, non-adhesive film
- Safe to use: non-toxic, non-corrosive, non-flammable, and non-staining
- UL listed
|
Physical Characteristics
|
| Amount per bottle |
1 Quart |
| Appearance |
Opaque, cream colored, pourable liquid |
| Brookfield Viscosity (100 rpm) |
1200 cPs (25˚C) |
| Percent Non-Volatile Solids |
3.0 to 3.5%, one of the lowest in the industry |
| Temperature Stability |
Freeze/Thaw (10 cycles) Excellent, no phase separation
Higher Temperature (7 days @ 122˚F) Excellent, no phase separation |
| pH |
7.5 - 8.0 |
| Toxicity |
Non-Toxic and Non-Sensitizing |
| Temperature Use Range |
20°F to 140°F (-7°C to 60°C)
|
| Flammability |
ASTM D93 (PMCC) - Product has no flash point, residue has no significant flammability |
| Compatibility with Cable Jackets |
IEEE/ICC P1210 |
| Lubricity |
(150 lb/ft sidewall load @ 65 fpm pulling speed)
coefficient of kinetic friction < 0.09 |
| Clean-up |
Complete clean-up with water |
|
Certifications
|
| UL |
Compliant |
|
Packaging Information
|
| Packaging Quantity |
1 quart bottle |
| Product Weight |
2.12 lbs |
