This cable lubricant incorporates new lubricant technology to create a high-performance, water-based gel lubricant formulated for many difficult applications, such as 600 V and higher voltage-rated cables. It is designed to meet or exceed all cable pulling requirements with respect to viscosity, cling, drag, wetting, operational temperature range and reduction of pulling tension.
Features
- New technology for increased friction reduction; Will not be displaced by cables
- Especially effective for placement of large cables and long difficult pulls
- Very effective for conventional copper cables
- Can be pumped or installed using gel pak bags
- Compatible with all types of cable jackets
- Slow drying, leaving a lubricating, non-adhesive film
- Safe to use: non-toxic, non-corrosive, non-flammable, and non-staining
- UL listed
|
Physical Characteristics
|
| Amount per bottle |
1 Quart |
| Appearance |
Opaque, cream colored, gel liquid |
| Brookfield Viscosity (100 rpm) |
5000 cPs (25˚C) |
| Density |
Approximately 8.1 pounds per gallon |
| Percent Non-Volatile Solids |
5.0 to 5.5% |
| Temperature Stability |
Freeze/Thaw (10 cycles) Excellent, no phase separation
Higher Temperature (7 days @ 122˚F) Excellent, no phase separation |
| pH |
7.0 - 8.0 |
| Toxicity |
Non-Toxic and Non-Sensitizing |
| Temperature Use Range |
20°F to 140°F (-7°C to 60°C)
|
| Flammability |
ASTM D93 (PMCC) - Product has no flash point, residue has no significant flammability |
| Compatibility with Cable Jackets |
IEEE/ICC P1210 |
| Lubricity |
(150 lb/ft sidewall load @ 65 fpm pulling speed)
coefficient of kinetic friction < 0.11 |
| Clean-up |
Complete clean-up with water |
|
Certifications
|
| UL |
Compliant |
|
Packaging Information
|
| Packaging Quantity |
1 quart bottle |
| Product Weight |
2.12 lbs |
